6 MobileView™ Tablet T750

Publication 2727-QS004B-EN-P - September 2004

5. Tap the IP address tab and select either “Obtain an IP address via DHCP” or

“Specify an IP address”, depending on your network configuration. If you
select to specify an IP address, you need to fill out the information in the
three text boxes with information from your network administrator or ISP.

Use the on-screen keyboard to enter the text. The on-screen keyboard is
accessed by taping the keyboard icon on the task bar.

DHCP option
selected

(1)

(2)

(3)

(1)

Must be a unique address from all others on the LAN.

(2)

Must be identical to the server subnet mask.

(3)

This is optional.

6. Tap OK in the settings dialog box. A notification appears, informing you that

you will need to either remove and reinstall your card or restart the
computer for your new settings to take effect. Tap OK.

7. Tap OK in the Network Configuration dialog box.

8. Press and quickly release the Reset button with the stylus to restart the

Tablet.

Do not press and hold in the reset button for more than a
second or you will start a full reset where all data on the Tablet
is deleted and parameters are reset to their initial default
settings.

IMPORTANT
