Rockwell Automation 2705-DN42 DeviceNet Interface Communicaton Board User Manual
Page 8

8
If an output error is detected, the RediSTATION sets the appropriate
message bits and remains in run mode.
In run mode, you can configure the outputs to:
•
turn on
•
turn off
•
flash
DIP switch 10 controls the rate of flashing for outputs.
The RediSTATION also supports DeviceNet configuration messages
that are received over the network.
Error Mode
In error mode (LED turns red), the RediSTATION monitors the error
state for correct operation. Errors are critical or noncritical.
Error Type
Description
LED State
Failure of diagnostic tests during powerup/reset mode
C i i l
Over-temperature condition of outputs during runtime
Critical
No e o e
le)
Changes to DIP switches during runtime
Solid Red
(Not recoverable)
Duplicate node address detected
Solid Red
Incorrect data rate
Non-C i i l
Pilot lamp burned out – open circuit on output
Non-Critical
Re o e
le)
Pilot lamp wired incorrectly – short circuit/overload
Flashing Red
(Recoverable)
I/O connection timeout
Flashing Red
See the troubleshooting chart for details on how to recover from an
error.
