3 - using the scanner, Chapter objectives, Physical description – Rockwell Automation 2755-G3-W_G6-W Scanner with Wedge Option User Manual
Page 17: Using the scanner
A–B
3
Chapter
3–1
Using the Scanner
This chapter covers some basic topics on the
operation and use of the scanner including:
•
Physical Description
•
LED Indicators
•
Safety Labels
•
Scanning Ranges
•
Operating Scanner
•
Beep
•
Operating Tips
•
Troubleshooting
The scanners use a low power visible laser diode light
source for non-contact scanning applications.
The trigger in the handle of the scanner turns on the
light beam. The beam exits the window on the front
of the scanner.
Trigger
Cable Connection
Scanning Window
LED Indicators
Note: If your scanner is enabled for Autosense
mode, the internal object sensor is automatically
triggered when bar codes are presented to it.
Chapter
Objectives
Physical
Description
