Chapter 3
The Menus
3–5
F7 – Supervisor Menu
The Supervisor Menu is used to configure NM for a specific site and is used for
occasional maintenance. The Supervisor Menu will look something like this:
DH5 Network Manager V5.0 Mar 04, 1991 07:41:28 am
F1 : Help
F2 : Change Configuration
F3 : Initiate Comm
F4 : Terminate Comm
F5 : Direct Interaction
F6 : Begin a loaded program
F7 : Abort a program
F8 :
F9 :
F10:
Exit Service
Supervisor Menu
Network Status
Current Site : NM
Stations Online : 1
Stations Offline : 0
Records Input : 0
Records Output : 0
Network Com Active
Help
The Help that is available from the Supervisor Menu is the same Indexed
Help that is available from the Main Menu. Refer to the previous discussion
of Help from the Main Menu.
Change Configurations
Note: You MUST choose the Save Changes (F9/‘S’) option before exiting
the Change Configuration menu or you will lose whatever changes you make
here.
The Change Configuration Menu is used to conf igure a specific site. The
Network Layout, communication parameters, special NM options and Menu
Editing are all sub–functions of the Change Configuration menu. The
Change Configuration menu should appear as follows when initiated. A
discussion of the topics under the Change Configuration menu follows this
section on the Supervisor Menu.
