Rockwell Automation 2090-CPxxx Continuous-flex Power and Brake Extension Cable with DIN Connector - Manual (Page 7)

Continuous-flex Power and Brake Extension Cable with SpeedTec Connector 7
Publication 2090-IN028B-EN-P - January 2011
Specifications
These specifications provide information that is useful when installing a cable. Additional
specifications are available in the Kinetix Motion Control Selection Guide
, publication
GMC-SG001 .
2090-CPBM7E7-xxAFxx Cables
Attribute 2090-CPBM7E7-
16AFxx
2090-CPBM7E7-
14AFxx 2090-CPBM7E7-
10AFxx 2090-CPBM7E7-
08AFxx
Wire size 16 AWG 14 AWG 10 AWG 8 AWG
Diameter 12.5 mm (0.50 in.) 13.7 mm (0.54 in.) 17.8 mm (0.70 in.) 20.5 mm (0.81 in.)
Bend radius (1)
(1) Apply the bend radius multiplier for operational (12 x dia.) and static (10 x dia.) bend radius to cables with a different
diameter. Refer to the diagram to locate the areas for flex (operational) and static (installation) bend areas.
Flex area 150 mm (6.0 in.) 165 mm (6.5 in.) 214 mm (8.5 in.) 250 mm (9.8 in.)
Installation area (2)
(2) The installation areas are approximately 300 mm (12 in.) in length at both ends of the cable. Secure this area with a rigid
mount that prevents the cable from flexing where it connects to other components.
125 mm (5.0 in.) 137 mm (5.5 in.) 178 mm (7.1 in.) 205 mm (8.1 in.)
