6 Continuous-flex Power and Brake Extension Cable with SpeedTec Connector

Publication 2090-IN028B-EN-P - January 2011

Schematics and Connector Pinouts for Cables

Wire colors and connector pinouts necessary to connect the cable to a servo system are shown in
the schematics.

2090-CPBM7E7-xxAFxx Cables

This power with brake cable is available in several wire gauges and lengths. The type of SpeedTec
connector varies with the wire gauge. Refer to the Kinetix Motion Control Selection Guide,
publication

GMC-SG001

, for this information and additional specifications.

C

B

A

E

F

G

H

L

C

B

A

E

F

G

H

L

Shield

Brown

Black

Blue

Green/Yellow

18 AWG White
18 AWG Black

U

V

W

U

V

W

A

B
C

A

B
C

F

G

E

H

L

F

G

E

H

L

MBRK+
MBRK-

MBRK+
MBRK-

+

-

1
2

+

-

1
2

Twisted Wire Pair

Connector Backshell Shielded 360°

Shield

2090-CPBM7E7-14AFxx
2090-CPBM7E7-16AFxx

2090-CPBM7E7-08AFxx
2090-CPBM7E7-10AFxx

Shield Connection
