GuardPLC 16-Digital Inputs and 8-Digital Outputs Module 23
Publication 1753-IN011A-EN-P - October 2005
Total Output Current
max. 8 A
Pulsed Outputs
No. of Outputs
2 (not electrically isolated)
Output Voltage
≥L+ minus 4V
Output Current (L+)
Approx. 60 mA
Minimum Load
none
Switching Time
≤ 100 micro-seconds
Overload Response
2 x
≥ 19.2V, short-circuit current 60 mA @ 24V
Environmental Conditions
Storage Temperature :
-40...+85 °C (-40...+185 °F)
• IEC 60068-2-1 (Test Ab, Unpackaged non-operating cold)
• IEC 60068-2-2 (Test Bb, Unpackaged non-operating dry heat)
• IEC 60068-2-14 (Test Na, Unpackaged non-operating thermal shock)
Operating Temperature:
0...+60 °C (+32...140 °F)
• IEC 60068-2-1 (Test Ad, operating cold)
• IEC 60068-2-2 (Test Bd, operating dry heat)
• IEC 60068-2-14 (Test Nb, operating thermal shock)
Vibration
1 g @ 10…150 Hz
• IEC 60068-2-6 (Test Fc, operating)
Shock, Operating
15 g
• IEC 60068-2-27 (Test Ea, unpackaged shock)
Relative Humidity
10 to 95% non-condensing
• IEC 60068-2-30 (Test Db, unpackaged non-operating damp heat)
Emissions
Group 1, Class A
ESD Immunity
6 kV contact discharges
8 kV air discharges
Radiated RF Immunity
10V/m with 1kHz sine-wave 80% AM from 80 MHz to 2000 MHz
EFT/B Immunity
±2 kV @ 5 kHz on power ports
±1 kV @ 5 kHz on signal ports
±1 kV @ 5 kHz on communication ports
Surge Transient Immunity
±1 kV line-line (DM) and ±1 kV line-earth (CM) on DC power ports
±500V line-line (DM) and ±1 kV line-earth (CM) on signal ports
±1 kV line-earth (CM) on communication ports
Conducted RF Immunity
10Vrms with 1 kHz sine-wave 80% AM from 150 kHz to 80 MHz
Enclosure Type Rating
meets IP20
Mechanical Dimensions
Width
205 mm (8.07 in.) including housing screws
Height
114 mm (4.49 in.) including latch
Depth
88 mm (3.46 in.) including grounding bolt
Weight
1.3 kg (2.86 lb)
