GuardPLC 16-Digital Inputs and 8-Digital Outputs Module 13
Publication 1753-IN011A-EN-P - October 2005
Surge on Digital Inputs
An EN 61000-4.5 surge impulse can be read as a short duration HI signal. To avoid
an error:
• install shielded input lines to prevent effects of surges in the system, or
• implement software filtering in the user program. A signal must be present
for at least two cycles before it is used by the rest of the logic in the user
program.
Line Control
Line control is a short-circuit and line break monitoring system (for example, E-Stop
inputs) which can be configured for the GuardPLC system.
57
11
Digital input 11
58
12
Digital input 12
59
L-
Reference pole
60
L-
Reference pole
61
Ground
Shield
62
Ground
Shield
63
LS+
Sensor supply for inputs 13 to 16, 40 mA buffered/1 A non-buffered
64
LS+
Sensor supply for inputs 13 to 16, 40 mA buffered/1 A non-buffered
65
13
Digital input 13
66
14
Digital input 14
67
15
Digital input 15
68
16
Digital input 16
69
L-
Reference pole
70
L-
Reference pole
71
Ground
Shield
72
Ground
Shield
IMPORTANT
For information on how to configure inputs and outputs for line
control, see the GuardPLC System User Manual, publication
number 1753-UM001.
Terminal Number
Designation
Function
