Before you begin, Determine module slot location – Rockwell Automation 1756-EN2TXT ControlLogix-XT EtherNet/IP Bridge Module User Manual
Page 9
ControlLogix-XT EtherNet/IP Bridge Module 9
Publication
1756-IN635A-EN-P - March 2009
Before You Begin
Complete these tasks by using the resources listed as references
before you install your module.
Determine Module Slot Location
Install the module in any open slot of the ControlLogix-XT chassis.
You can install multiple 1756-EN2TXT modules in the same chassis.
Task
Resource
Install a ControlLogix-XT chassis
Install a ControlLogix-XT power supply
Slot 0
Slot 1
Slot 2
Slot 3
31818-M
Slot 4
