18 POINT I/O Module with 8 Configurable 24V DC Points and DeviceLogix
Publication
1734-IN039A-EN-P - March 2009
Data [38]
Peer 5 - EPR (ms)
Data [39]
Data [40]
Peer 6 - Slot/MacID
Data [41]
Peer 6 - Consume Message Length (bytes)
Data [42]
Peer 6 - EPR (ms)
Data [43]
Data [44]
Peer 7 - Slot/MacID
Data [45]
Peer 7 - Consume Message Length (bytes)
Data [46]
Peer 7 - EPR (ms)
Data [47]
Where:
•
Filter = 0 to 65535
μ
s (1000 = default)
•
FltM = Fault Mode (0 = Fault Value (default), 1 = Hold Last State)
•
FltV = Fault Value (0 = OFF (default), 1 = ON)
•
IdlM = Idle Mode (0 = Idle Value (default), 1 = Hold Last State)
•
IdlV = Idle Value (0 = OFF (default), 1 = ON)
•
RACK = Produce with Rack Assembly 4 and Consume Rack Assembly 34
(0 = Disabled (default), 1 = Enabled)
•
CFO = DeviceLogix Communication Fault Override of Outputs
1 = Enabled. When enabled, the DeviceLogix program will continue to control the
outputs even in the event of a communication fault.
0 = Disabled (default). When disabled, the outputs will follow the Fault and Idle
settings.
•
DM = Dependent Mode
•
MP = Masterless Produce
0 = Disabled (default), 1 = Enabled. When enabled, the module will begin producing
data at powerup and after a connection with a controller is terminated.
Data Map - Configuration Assembly Instance 123 (Continued)
Message Size: 48 Bytes
