16 POINT I/O Module with 8 Configurable 24V DC Points and DeviceLogix

Publication

1734-IN039A-EN-P - March 2009

You can select other consumed assemblies:

Consumed assembly instance 34 is the first byte of consumed
assembly instance 102 (Data [0]).

Consumed assembly instance 112 is the first eight bytes of consumed
assembly instance 102 (Data [0]…[7]).

In RSLogix5000, the default tags will be:

AdapterName:SlotNumber:O.Data

AdapterName:SlotNumber:O.LogicDefinedData

AdapterName:SlotNumber:O.LogicDefinedIntData[0...7]


Data Map - Configuration Assembly Instance 123

Message Size: 48 Bytes

Bit

7

6

5

4

3

2

1

0

Data [0]

Group Off2On Input filter

Data [1]

Data [2]

Group On2Off Input filter

Data [3]

Data [4]

FltM 7

FltM 6

FltM 5

FltM 4

FltM 3

FltM 2

FltM 1

FltM 0

Data [5]

FltV 7

FltV 6

FltV 5

FltV 4

FltV 3

FltV 2

FltV 1

FltV 0

Data [6]

IdlM 7

IdlM 6

IdlM 5

IdlM 4

IdlM 3

IdlM 2

IdlM 1

IdlM 0

Data [7]

IdlV 7

IdlV 6

IdlV 5

IdlV 4

IdlV 3

IdlV 2

IdlV 1

IdlV 0

Data [8]

Reserved

RACK

CFO

DM

MP

Data [9]

Reserved

Data [10]

Masterless Produce Assembly Instance (0, 4, 101, 111)

Data [11]

Data [12]

Masterless Produce EPR (ms)

Data [13]
