ControlNet Scanner Card
31
Publication 1784-5.35 – April 1999
Specifications
The operating parameters describe the environment within the KTCS slot.
Refer to the documentation for your computer for environmental requirements.
The card should not exceed those specifications.
General Specifications
Characteristic
Value
Power
Requirements
5V dc, 640mA Maximum
Conductor
Category 2
1
Environmental Specifications
Operating
Nonoperating
Slot Temperature
0 to 50
°
C (32 to 122
°
F)
– 40 to 85
°
C (– 40 to 185
°
F)
Humidity
5 to 95% without condensation
5 to 95% without condensation
Vibration
10 to 150 Hz, constant .012 in
displacement
10 to 150 Hz, constant 2.0G
acceleration
not applicable
Shock
30G peak/11 ms
50G peak/11 ms
Agency Certification
(when product or packaging is marked)
Class 1, Division 2
Groups A, B, C, D
П
П
П
П
ПП
ПП
П
П
marked for all applicable directives
1
Refer to the Industrial Automation Wiring and Grounding Guidelines for Noise Immunity,
publication 1770-4.1
