ControlNet Scanner Card
21
Publication 1784-5.35 – April 1999
10. Click Next to continue.
The wizard prepares to reset the card, and reports Card has been reset.
LEDs should be alternating green and red. Congratulations, the check wizard
has verified proper configuration of your 1784-KTCS card in your computer.
If the wizard fails, check the I/O base address on the card against the I/O base
address you entered into the wizard. If the check wizard fails and the card I/O
address and wizard address are identical, call Rockwell Automation Technical
Support at 440-646-6800 for assistance.
Connecting the Card
After you have installed the card, you can connect it:
•
to a device already connected to the ControlNet network via the 1786-CP
network access port cable (page 23)
Important:
This is only a temporary connection. As a permanent
connection, the KTCS card should connect via a
ControlNet tap.
•
directly to a ControlNet network via a ControlNet tap (page 26)
