9
Publication 1769-IN077A-EN-P - May 2006
Mount Module to Panel Using Modules as a Template
This procedure lets you use the assembled modules as a template for drilling holes in the
panel. Refer to Mount Module to Panel Using the Dimensional Template on page 8 if you
have sophisticated panel-mounting equipment. Due to module-mounting hole tolerance, it is
important to follow this procedure:
1. On a clean work surface, assemble no more than three modules.
2. Using the assembled modules as a template, carefully mark the center of all
module-mounting holes on the panel.
3. Return the assembled modules to the clean work surface, including any previously
mounted modules.
4. Drill and tap the mounting holes for the recommended M4 or #8 screws.
5. Place the modules back on the panel, and check for proper hole alignment.
6. Attach the modules to the panel using the mounting screws.
7. Repeat steps 1 to 6 for any remaining modules.
Mount Module to DIN Rail
The module can be mounted using these DIN rails:
• 35 x 7.5 mm (EN 50 022 - 35 x 7.5)
• 35 x 15 mm (EN 50 022 - 35 x 15)
Before mounting the module on a DIN rail, close the DIN-rail latches. Press the DIN-rail
mounting area of the module against the DIN rail. The latches will momentarily open and
lock into place.
TIP
If mounting more modules, mount only the last one of this group and put
the others aside. This reduces the remounting time during drilling and
tapping of the next group.
