13
Publication 1769-IN077A-EN-P - May 2006
Configuration Data File
The manipulation of bits from this file is normally done with programming software (for
example, RSLogix 500 software or RSNetWorx for DeviceNet software) during initial
configuration of the system. In that case, graphical screens provided by the programming
software simplify configuration.
Some systems, like the 1769-ADN DeviceNet adapter system, also allow the bits to be altered
as part of the control program using communication rungs. In that case, it is necessary to
understand the bit arrangement. Words 0 and 1 of the configuration data file set the input
control parameters for the module. Words 2 to 7 set the alternate output state operation of
the module. Each output point’s operating parameters are controlled by a group of eight
words.
Wo
rd
Bit Position
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 Input Filter
1 IT_
I7
EI_
I7
IT_
I6
EI_
I6
IT_
I5
EI_
I5
IT_
I4
EI_
I4
IT_
I3
EI_
I3
IT_
I2
EI_
I2
IT_
I1
EI_
I1
IT_
I0
EI_
I0
2 PFE
3
4 PM3 PM2 PM1 PM0
5 PV3 PV2 PV1 PV0
6 FM3 FM2 FM1 FM0
7 FV3 FV2 FV1 FV0
8 IT_O0 EI_
O0
DB_
0
9 Operand_A_0
10 Operand_B_0
11 Operand_C_0
12 Operator_
2_0
Operator_
1_0
13 Output Delay 0
14 Output Duration 0
15
16 IT_O1 EI_
O1
DB_
1
17 Operand_A_1
18 Operand_B_1
19 Operand_C_1
