15
Publication 1769-IN077A-EN-P - May 2006
IT_Ox: Output interrupt type. See page 16.
Operand_A_x: BOOLEAN operand A. See page 17.
Operand_B_x: BOOLEAN operand B. See page 17.
Operand_C_x: BOOLEAN operand C. See page 17.
Operator_1_x: BOOLEAN operator 1. See page 19.
Operator_2_x: BOOLEAN operator 2. See page 19.
Output delay x: Delay time from BOOLEAN expression transition from false to true until output directed to transition from off to
on. See page 20.
Output duration x: Pre-determined output pulse duration time. Time from output directed to transition from off to on until output
directed to transition from on to off. See page 21.
Shaded bit positions must be set to 0.
Wo
rd
Bit Position
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 Input Filter
8 ms 0 0 0
0 s 0 0 1
100 µs 0 1 0
200 µs 0 1 1
500 µs 1 0 0
1 ms 1 0 1
2 ms 1 1 0
4 ms 1 1 1
