Rockwell Automation 1792D-CB18JP ArmorBlock MaXum I/O Cable Bases DeviceNet Powered Outputs Series B User Manual
Page 6
6 ArmorBlock MaXum I/O Cable Bases DeviceNet Powered Outputs Series B
Publication 1792D-IN001B-EN-P - September 2000
A mounting illustration for the 1792D-CB18JP is below.
42275
When
installing a
cable base
with an 8
connector
module,
allow for
the
additional
length.
2.70in.
68.5mm
0.791in.
20.1mm
1.90in.
48.18mm
8.23in.
209mm
8 connector
module
4.00in.
101.5mm
1.34in.
34mm
1.63in.
41.5mm
1.35in.
34.25mm
0.764in.
19.4mm
6.10in
155mm
4 connector
module
4.21in.
107mm
18mm
1792D-CB18JP
0.26in.
6.5mm
1.42in.
36mm
0.64in.
16.25mm
