Publication 1734-UM007D-EN-P - December 2005
2-4 Configure the Module
2. Refer to the dialogs for an explanation of features.
The module’s name appears
here.
Type a description here.
The module’s address appears
here. (This field is read only.)
This dialog also shows the
module’s device identity.
These fields are read only.
At any point, you can click here to finish
changing configuration parameters.
If configuration changes are made in offline
mode, they do not take effect until the
system goes online.
Click the Device parameters tab to
get to the dialog for setting the
parameters.
This dialog appears after you click
the Device parameters tab. If you
want the existing parameters
uploaded from the module, click
Upload. The following dialog then
shows the existing parameters set
on the module.
Use this menu to edit or view
the parameters. Available
choices are:
Configuration
