Chapter
2
Publication 1785Ć10.3 - October 1996
Set up the Hardware
Install the hardware
(page
2-2
)
Connect the programming terminal
and the PLCĆ5 processor to the
communication card
(page 2Ć6)
1
2
PC with programming
software installed
terminal
cable
PLCĆ5/25
For more information, see the Classic PLC-5 Programmable
Controllers Hardware Installation Manual, publication number
1785-6.6.1.
