Appendix
Publication 1785Ć10.3 - October 1996
Specifications
This table lists general specifications.
Weight PLCĆ5/10 (1785ĆLT4) 1336 g (47.12 oz.)
PLCĆ5/12 (1785ĆLT3) 1337 g (42.15 oz.)
PLCĆ5/15 (1785ĆLT) 1339 g (47.23 oz.)
PLCĆ5/25 (1785ĆLT2) 1337 g (42.15 oz.)
Backplane Current 2.5A
Environmental Conditions:
operating temperature 0 ° to 60 ° C (32 ° to 140 ° F)
storage temperature Ć40 ° to 85 ° C (Ć40 ° to 185 ° F)
relative humidity 5 to 95% (without condensation)
Vibration
(operating and nonĆoperating)
1 g @ 10 to 500 Hz
0.012 inches peakĆtoĆpeak displacement
Shock
operating 30 g peak acceleration for 11 ± 1 ms duration
nonĆoperating 50 g peak acceleration for 11 ± 1 ms duration
TimeĆofĆDay Clock and Calender
maximum variations at
60 ° C
± 3 min per month
typical variations at 20 ° C ± 20 s per month
timing accuracy one program scan
Typical Discrete I/O Scan • 1ms/local I/O rack
• 10 ms/remote I/O adapter communication at 57.6 kbps
I/O Modules Bulletin 1771 I/O including 8Ć, 16Ć, 32Ćpt., and intelligent modules
Hardware Addressing:
2Ćslot • any mix of 8Ćpt modules
• 16Ćpt modules must be I/O pairs
• no 32Ćpt modules
1Ćslot • any mix of 8Ć or 16Ćpt modules
• 32Ćpt modules must be I/O pairs
1/2Ćslot any mix of 8Ć,16Ć, or 32Ćpt modules
Communication • DH+ 3,048 cableĆm (or 10,000 cableĆft) max
• DH using 1785ĆKA
Location 1771ĆI/O chassis, leftĆmost slot
Keying • between 40 and 42
• between 54 and 56
Agency Certification
(when product is marked) • CSA certified
• CSA Class I, Division 2, Groups A, B, C, D
• UL listed
User Manual publication 1785Ć6.2.1
General
