Chapter
3
Publication 1785Ć10.3 - October 1996
Set up the Software
Powerup the system
3
Install the software
1
Start the programming software
2
The following instructions are general. For specific information, see
the documentation set for your particular software package.
Before you install your programming software, make certain you
meet the system requirements for that software – sufficient disk
space, memory, etcetera. Then, follow the procedures outlined in the
software documentation to install the software and configure
communication.
Start the programming software by following the procedures
described in your programming software documentation.
If you have difficulty, verify that the power supply is turned on.
To monitor your system as you configure and run it, check the LED
display for the following indicators:
This LED:
lights when:
COMM
you establish DH+ communication
BATT
no battery is installed or the battery voltage is low
REM I/O
you establish Remote I/O communication
ADAPT
the processor is in adapter mode
FORCE
forces are present in your ladder program
