Page 7
USB-to-ControlNet Cable 7
Publication
1784-IN047A-EN-P - November 2008
3.
Insert the end of the cable having the RJ45 network connector into
the ControlNet network access port (NAP) of a ControlNet
network-enabled device.
Traffic Analyzer Software
The 1784-U2CN cable is designed to work with Frontline’s NetDecoder
traffic analyzer software. For more information on Frontline’s product, go to
either
USB Cable
RJ45 ControlNet Network Connector
