Configure and connect the cable – Rockwell Automation 1784-U2CN USB-to-ControlNet Cable Installation Instructions User Manual
Page 6
6 USB-to-ControlNet Cable
Publication
1784-IN047A-EN-P - November 2008
Configure and Connect the Cable
1.
Use the rotary switches to set the module node address to a valid
number (1…99).
2.
Insert the end of the cable having the USB connector into a USB port
on a computer.
ATTENTION
USB and ControlNet connection lengths must be less than 3 meters. Do not
attempt to extend the cables.
Node Address
(Rotary) Switches
