Specifications
8 Input / 8 Output Module - Cat. No. 1792D-88HC
Input Specifications Max. Min.
Inputs per block 8, Configurable as sinking or sourcing in two groups of 4
sourcing type is default
Off-State Voltage 4 0
On-State Voltage 30 8
Off-State Current - 1.2mA
On-State Current 11mA (@30V dc) 2mA (@10V dc)
Output Specifications Max. Min.
Outputs per block 8 sourcing type in two groups of 4
Off Peak Blocking Voltage - 30V
On-State Voltage Drop 5Amp
10 Amp 1V
1V -
-
On-State Current 5 Amp
10 Amp 5A
10A -
-
Off-State Leakage 5 Amp
10 Amp 250uA
250uA -
-
Module Current (all outputs) 40A -
Surge Current - for 10mS 5 Amp
repeatable every 2 sec.
10 Amp
10A
20A -
-
General Specifications Max. Min.
DeviceNet Power: Voltage
Current 25V dc
75mA 11V dc
125mA
Auxiliary Power Voltage
Group 1 and Group 2 Current
30V dc
40A
8V dc (inputs)
10V dc (outputs)
40A
Indicators Net/Mod Status-red/green Auxiliary Power-yellow
Logic Status-green Input Point LED-yellow
Output Point LED-red/green
Communication Rate
• 125Kbps @ 500 meters (1600 feet) for thick cable,
flat media length 375 meters
• 250Kbps @ 200 meters (600 feet) for thick cable, flat
media length 150 meters
• 500Kbps @ 100 meters (300 feet) for thick cable, flat
media length 75 meters
Dimensions (assembled to base)
inches - (millimeters) 2.63H x 7.74W x 3.06D
(66.7H x 196.6W x 77.60D)
