12 High Current 8 Input/8 Output ArmorBlock I/O Module Series B
Publication 1792D-IN005D-EN-P - February 2002
The following table describes the logic status indicator.
The following table describes the I/O status indicator.
For more information on indications, see the Technical Data,
publication 1792-TD001.
Logic Status Indicators
State Status
Off Logic is disabled
Solid Green Logic is enabled
Flashing Green Local forces are applied and local logic is enabled
I/O Status Indicators
Function LED
Color
Condition Module Illumination
Auxiliary
Power
Group #1 Yellow No auxiliary power
Auxiliary power present
None
Yellow
Auxiliary
Power
Group #2 Yellow No auxiliary power
Auxiliary power present
None
Yellow
Outputs Green/
red Output not energized
Output energized
Output shorted and latched off
Output No-load in OFF state None
Green
Red, MS blink red
Blinking Red, MS blink Red
Inputs Yellow No valid input
Valid input
None
Yellow
