Configuring the kfc15 module using rotary switches – Rockwell Automation 1747-KFC15 SLC500 CONTROLNET RS-232 USER MANUAL User Manual
Page 23
Configuring the KFC15 Module
2-5
1747-5.34 - June 1998
Configuring the KFC15 Module Using Rotary Switches
The KFC15’s ControlNet network address is set by the rotary switches S4
and S5. Switch S5 sets the upper digit of the address and S4 the lower.
These switches can be turned manually by hand while holding the module
in the orientation illustrated below.
Rotary Switches S5
and S4 respectively
S5
S4
