15

Qˆiyvph‡v‚Ã &'#$" ñÃPp‡‚ir…à (((

Configure Port

You must configure the port the first time you use
a PCIDS card.

To configure the port, follow these steps:

1. Select Configure Port... from the Setup menu.

2. Select Allen-Bradley 1784-PCIDS from

WinDNET32 Driver Selection dialog.

3. Press OK.

4. Set Node Address (0 - 63).

5. Set Baud Rate (125/250/500 kbs).

6. Press OK.

You see a message box: Operation was successful
followed by a similar message box:
Port “DeviceNet Port A” has been configured.

Create View

To go online, follow these steps:

1. Select Create View... from the Setup menu.

2. Select Port Names.

3. Select Message Type (Input, Output, or

Input/Output).

4. Select Privilege (Read Only, Read/Write).

5. Press OK.

You see a message box: Operation was successful.

Scanner Mode

The Port Mode window displays the current mode
of the scanner: Run, Idle, No View.

1784531_1099.fm Page 15 Friday, October 22, 1999 5:42 PM
