Installing the 1784-pcid(s) card – Rockwell Automation 1784-PCIDS DEVICENET PCI COMM User Manual
Page 11

11
Qiyvphvà &'#$" ñÃPpir à (((
,
QVWDOOLQJ WKH
3&,'6 &DUG
Important: Make sure you know how to:
•
install hardware in your computer
•
configure the computer’s options before you
install the PCID(S)
Consult your computer’s documentation for
specific information.
You need a Phillips-head or a flat-head
screwdriver, depending on your system.
To install the card:
1. Gain access to the computer’s expansion slots.
2. Insert the card into an open PCI slot in the
computer.
Note: The 1784-PCID(S) card is 4.2”
(10.7 cm) high and 4.721” (12 cm) long.
30138-M
´
´
FP
FP
