12

Qˆiyvph‡v‚Ã &'#$" ñÃPp‡‚ir…à (((

Accessing the Computer’s Expansion Slots

To install the PCID(S) card, you must access the
computer’s expansion slots. Refer to your
computer’s user guide for instructions on how to:

1. Power down the host computer by turning off

the power switch.

2. Remove the computer’s cover.

3. Select a vacant PCI expansion slot.

4. Remove the slot’s expansion cover by

loosening the screw on the back (rear bracket)
of the computer.

Inserting the Card

To insert the card inside the computer:

1. Follow the card handling instructions on

page 6.

2. Insert the PCID(S) card into the edge connector

and tighten the expansion slot screw.

3. Turn on the computer to make sure it powers

up correctly.

4. Replace the CPU cover (when computer comes

up correctly).

1784531_1099.fm Page 12 Friday, October 22, 1999 5:42 PM
