Specifications
Inputs per module 16 single-ended; 8 differential low level
Module Location 1771 I/O rack - 1 slot
Input voltage ranges (nominal)
+1 to +5V dc
0 to 5V dc
-5 to +5V dc
-10 to +10V dc
0 to +10V dc
Input current ranges (nominal)
+4 to +20mA
0 to +20mA
-20 to +20mA
Resolution 12-bit binary
12 bits plus sign on bipolar ranges
Accuracy 0.1% of full scale range @ 25 o C
Linearity +1 LSB
Repeatability +1 LSB
Isolation Voltage +1500V, (transient)
Input overvoltage protection
200V (voltage mode) 1
8V (current mode) 2
Input overcurrent protection (current ranges) 30mA
Common mode voltage
+14.25 Volts
Input impedance 100 Megohms for voltage ranges; 250 ohms for current ranges
Common mode rejection 80 db, DC-120 Hz
Current Requirements 0.75A @ +5V from I/O chassis backplane
Power Dissipation 3.75 Watts (maximum)
Thermal Dissipation 12.8 BTU/hr (maximum)
Unscaled BCD and binary output to
processor
0000 to +4095
10
for polar ranges (0 to 5V, +1 to +5V, 0 to +20mA,
and +4 to +20mA)
-4095
10
to 4095
10
for bipolar ranges ( +5V, +10V, +20mA)
Engineering units sent to processor +9999
10
with selectable scaling
Internal scan rate
12.5 ms for 8 differential inputs (no digital filtering) -add 2.12ms for filtering
25 ms for 16 single-ended input (no digital filtering) -add 4.24 for filtering
Environmental conditions
operational temperature:
storage temperature:
relative humidity:
0 to 60 0 C (32 to 140 0 F)
-40 to 85 0 C (-40 to 185 0 F)
5 to 95% (without condensation)
Conductors Wiring
Category
14 gauge stranded (max.)
3/64 inch insulation (max.)
Category 2 3
Keying
between 10 and 12
between 24 and 26
Wiring Arm Catalog Number 1771-WG
Field Wiring Arm Screw Torque 7Ć9 inchĆpounds
1 The inputs are protected to 200V. However, if an input terminal's voltage exceeds +14.25V as referenced to module common, channelĆtoĆchannel crosstalk
can cause invalid input readings and invalid underrange/overrange bits.
2 Only 8 volts can be placed directly across the input when configured in the current mode.
3 Refer to publication 1770-4.1, "Programmable Controller Wiring and Grounding Guidelines."
