Rockwell Automation 1771-OA AC (120V) Output Module - Manual (Page 12)

AC Output Module 12
Publication 1771-IN080A-EN-P - November 2002
Power Dissipation 10.7 Watts (max.), 1.1 Watts (min.)
Thermal Dissipation 36.6 BTU/hr (max.), 3.4BTU/hr (min.)
Adjacent Slot Power Dissipation 15 Watts
Backplane Current 210mA @ 5V dc 5%
Opto-electrical Isolation Tested to 1500V ac rms for 2s
Environmental Conditions
Operational Temperature IEC 60068-2-1 (Test Ad, Operating Cold)
IEC 60068-2-2 (Test Bd, Operating Dry Heat)
IEC 60068-2-14(Test Nb, Operating Thermal Shock)
32 to 140°F (0 to 60°C)
Storage Temperature IEC 60068-2-1 (Test Ab, Unpackaged, Nonoperating Cold)
IEC 60068-2-2 (Test Bb, Unpackaged, Nonoperating Dry Heat)
IEC 60068-2-14(Test Na, Unpackaged, Nonoperating Thermal Shock)
-40 to 185°F (-4 0 to 85°C)
Relative Humidity IEC 60068-2-30 (Test Db, Unpackaged, Nonoperating Damp Heat)
5 to 95% noncondensing
Shock
Operating
Nonoperating
IEC 60068-2-27 (Test Ea, Unpackaged Shock)
30g
50g
Vibration IEC 60068-2-6 (Test Fc, Operating)
2g @ 10-500Hz
Enclosure Type Rating None (open style)
Keying Between 4and 6
Between 12 and 14
Fuses 2A, 250V Buss AGC2 fuse
Field Wiring Arm Cat. No. 1771-WA
Field Wiring Arm Screw Torque 9 pound-inches (0.7Nm)
Conductors Wire Size
Category
14-22AWG (2.5-0.25mm 2 ) stranded copper wire rated at 75 o C or
greater 1
3/64inch (1.2mm) insulation (max)
1 2
Certifications
(when product is marked)
UL UL Listed Industrial Control Equipment
c-UL UL Listed for Class I, Division 2, Group A, B, C, D
Hazardous Locations, certified for Canada
1 One or two 14-22 AWG solid or stranded copper wires per terminal. Must be same size. Do not intermix solid and stranded wires.
Use copper wire only.
2 Use this conductor category information for planning conductor routing . Refer to publication 1770Ć4.1, Industrial Automation Wiring and
Grounding Guidelines."
