PointBus Status
Off
Device is not powered - check module status indicator.
Alternating Red/Green
LED powerup test.
Flashing Red
Recoverable fault has occurred:
- at power up the number of expected modules does not
equal the number of modules present
- a module is missing
- node fault (I/O connection timeout).
Red
Unrecoverable fault has occurred:
- the adapter is bus off
- the adapter has failed its dup_MAC_ID check.
Flashing Green
Adapter is on line with no connections established:
- adapter chassis size has not been configured
- controller in program/Idle mode
- ControlNet cable break.
Green
Adapter is on line with connections established (normal
operation, in run mode).
ControlNet A/B
Status (Viewed
together)
Both Steady Off
Reset, no power or entire network interface deactivated.
Alternating Red/Green
Self test mode.
Alternating Red/Off
Bad/invalid node configuration (such as dup_MAC_ID).
Both Steady Red
Failed link interface.
ControlNet A/B
Status (Viewed
individually)
Steady Off
Channel disabled or channel not supported.
Flashing Red/Green
Invalid link configuration.
Flashing Red/Off
Severe link error - link fault or no MAC frames received.
Flashing Green/Off
Temporary channel error or listen-only.
Steady Green
Normal operation - MAC frames are being received without
detected error.
System Power
Off
Not active - Field power is off or dc-dc converter problem.
Green
Power on - dc-dc converter active (5V).
Adapter Power
Off
Not active - Field power is off.
Green
Power on - 24V present.
Indication
Indication
Probable Cause
