DC Output Driver Module

Publication 1771-IN076A-EN-P - October 2002

Certifications

(when product is marked)

ULUL

isted Industrial Control Equipment

CSA

CSA Certified Process Control Equipment

European Union 89/336/EEC EMC Directive,

compliant with:

EN 50082-2, Industrial Immunity

EN 61000-6-2, Industrial Immunity

EN 61000-6-4, Industrial Emissions

C-Tick

Australian Radiocommunications Act, compliant with:

AS/NZS 2064, Industrial Emissions

One or two 14-22 AWG solid or stranded copper wires per terminal. Must be same size. Do not intermix solid and stranded wires.

Use copper wire only.

Use this conductor category information for planning conductor routing . Refer to publication 1770Ć4.1, Industrial Automation Wiring and

Grounding Guidelines."

See the Product Certification link at www.ab.com for Declarations of Conformity, Certificates and other certification details
