9 120V ac FLEX I/O 8 Input Module (Cat. No. 1794ĆIA8)
Publication 1794Ć5.9
Specifications - 120V ac Input Module Cat. No. 1794ĆIA8
Power Dissipation Maximum 3.5W @ 132V ac
Thermal Dissipation Maximum 11.9 BTU/hr @ 132V ac
Indicators (field side indication,
customer device driven)
8 yellow status indicators
Keyswitch Position 8
General Specifications
External ac Power
Supply Voltage
Voltage Range
120V ac nominal
85 to 132V ac, 47Ć63Hz
Dimensions Inches
(Millimeters)
1.8H x 3.7W x 2.1D
(45.7 x 94.0 x 53.3)
Environmental Conditions
Operational Temperature
Storage Temperature
Relative Humidity
Shock Operating
NonĆoperating
Vibration
0 to 55 o C (32 to 131 o F)
-40 to 85 o C (-40 to 185 o F)
5 to 95% noncondensing
30 g peak acceleration, 11(+1)ms pulse width
50 g peak acceleration, 11(+1)ms pulse width
Tested 5 g @ 10-500Hz per IEC 68Ć2Ć6
Conductors Wire Size
Category
12 gauge (4mm 2 ) stranded maximum
3/64 inch (1.2mm) insulation maximum
1 1
Agency Certification
(when product or packaging is
marked)
• CSA certified
• CSA Class I, Division 2,
Groups A, B, C, D certified
• UL listed
• CE marked for all applicable directives
1 You use this conductor category information for planning conductor routing as described in
publication 1770Ć4.1, Industrial Automation Wiring and Grounding Guidelines."
