120V ac FLEX I/O 8 Input Module (Cat. No. 1794ĆIA8)

Publication 1794Ć5.9

Indicators

7

6

5

4

3

2

1

0

120 VAC INPUT

1794-IA8

8

AllenĆBradley

B

A

A = Status Indicators – yellow – show status of individual inputs.
B = Insertable label for writing individual input designations.

Image Table Memory Map


Table

Dec. Bits

(Oct. Bits)

Description

Format

Input

00-07

Status of input data

0-7

Input

08-15 (10-17) Not used

Output

00-02

Delay time for Inputs 0 to 7

Output

03-15 (3-17)

Not used

Dec.

15

14

13

12

11

10

09

08

07

06

05

04

03

02

01

00

(Oct.)

17

16

15

14

13

12

11

10

07

06

05

04

03

02

01

00

read

Not used - set to 0

I7 I6 I5 I4 I3 I2 I1 I0

write

Not used - set to 0

D

D

D

Where:

I = Input number

D = Delay time bit - see below
