20 SLC ControlNet Scanner Module
Publication 1747-IN059C-EN-P - September 2001
Specifications
SLC ControlNet Scanner Module - 1747-SCNR
Module Location
Slot 1 or above
Module Defaults
Node Address -00
Maximum Backplane Current 900 mA @ 5V dc
Isolation Voltage
Optical Isolation between backplane and ControlNet
channel 1 Megohm resistor from ControlNet channel
to chassis
Environmental Conditions:
Operational Temperature
Storage Temperature
Relative Humidity
0-60
°
C (32-140
°
F)
-40 to 85
°
C (-40 to 185
°
F)
5-95% without condensation
Shock unpackaged
30g operational
50g non-operational
Vibration Unpackaged
5g from 10-150Hz
Immunity Radiated Fields
10 V/m
27 mHz-1000 mHz
Agency Certification
(when product or packaging
is marked)
Reference Manual
1747-RM623
marked for all applicable directives
Listed Industrial Control Equipment for use in Class I
c
us
Division 2, groups A, B, C, D, Hazardous Locations. Suitable for
use in U.S. and Canada.
