24 DeviceNet Digital Base Terminal Block CompactBlock LDX I/O
Publication 1790-IN006C-EN-P - May 2006
EFT/B Immunity IEC 61000-4-4
±1 kV at 5 kHz on power ports
±2 kV at 5 kHz on signal ports
±2 kV at 5 kHz on communications ports
Surge Transient Immunity IEC 61000-4-5:
±1 kV line-line (DM) on power ports
±1 kV line-line (DM) on signal ports
±2 kV line-earth (CM) on communications ports
Conducted RF Immunity IEC61000-4-6
10V rms with 1 kHz sine-wave 80%AM at 150 kHz...80 MHz
Enclosure Type Rating None (open-style)
Mounting DIN rail or panel
Dimension 52 x 104 x 42 mm (2.03 x 4.07 x 1.64 in.)
Weight 0.1 kg (0.3 lb)
Wiring, Terminal Block
(M3.0) Screw Torque 7 lb-in max (use copper or copper-clad aluminum
conductors)
Wire Size
2.5…0.25 mm
2
(14 …22 AWG) solid or stranded copper
wire rated at 75 °C or greater 1.2 mm (3/64 in.) insulation
max
Wiring Category
(1) 2 - on signal ports
2 - on power ports
2 - on communications ports
dc Field Power Supply voltage - 24V dc nom
Voltage range - 10…28.8V dc
dc Relay Coil Power Supply voltage - 24V dc nom
Voltage range - 19.2…28.8V dc
ac Field Power Supply voltage - 115V ac, 60 Hz
Voltage range - 85…132V ac, 47…63 Hz
DeviceNet
DeviceNet Power Supply voltage - 24V dc nom
Voltage range - 8…28V dc
Environmental - Common To All Base Blocks in This Publication
