16 H-Series Motor Installation Instructions
Publication 1398-IN517A-EN-P — August 2001
Cables and Connector Kits
CE compliant cables are available from Allen-Bradley in standard cable
lengths. Contact your nearest Allen-Bradley sales office or refer to your
drive’s installation manual for a complete listing of available cables.
If you choose to build your own cables, the following non-CE compliant
connector kits are available for H-Series motors with optical encoders
.
ATTENTION
!
H-Series motors with high resolution encoders
require the use of Allen-Bradley power and
feedback cables.
H-Series connector kits do not provide the
necessary connector grounding for use with high
resolution encoders.
Failure to observe these safety procedures could
result in personal injury or equipment damage.
Catalog
Number Description
2090-HPC-S2000 Straight Power Connector Kit Compatible with 500W, 1 and 2 kW Drives
2090-HPC-R2000 Right-Angle Power Connector Kit Compatible with 500W, 1 and 2 kW Drives
2090-HPC-S3000 Straight Power Connector Kit Compatible with 500W, 1 and 2 kW Drives
2090-HPC-R3000 Right-Angle Power Connector Kit Compatible with 500W, 1 and 2 kW Drives
2090-HPC-S4000 Straight Power Connector Kit Compatible with 2 and 3 kW Drives
2090-HPC-R4000 Right-Angle Power Connector Kit Compatible with 2 and 3 kW Drives
2090-HPC-S6000 Straight Power Connector Kit Compatible with 7.5 kW Drives
2090-HPC-R6000 Right-Angle Power Connector Kit Compatible with 7.5 kW Drives
2090-HPC-S8000 Straight Power Connector Kit Compatible with Drives >7.5 kW
2090-HPC-R8000 Right-Angle Power Connector Kit Compatible with Drives >7.5 kW
