H-Series Motor Installation Instructions 15
Publication 1398-IN517A-EN-P — August 2001
Motor Radial Load Force Ratings
With no radial load, the axial load rating is 100% of the radial load rating
from the table above. With a radial and an axial load, the axial load rating
is 44% of the radial load rating from the table above.
Motor
500
RPM
1000
RPM
2000
RPM
3000
RPM
4000
RPM
5000
RPM
6000
RPM
H-2005 kg 63.5 50.8 39.9 34.9 31.8 29.5 20.4
(lb) (140) (112) (88) (77) (70) (65) (45)
H-3007 kg 68 54.4 43.1 37.6 34 31.8 –
(lb) (150) (120) (95) (83) (75) (70) –
H-3016 kg 76.2 60.8 47.6 41.7 38.1 35.4 –
(lb) (168) (134) (105) (92) (84) (78) –
H-4030-M kg 102.1 91.6 72.6 63.5 57.6 – –
(lb) (225) (202) (160) (140) (127) – –
H-4030-P kg 102.1 91.6 72.6 63.5 57.6 – –
(lb) (225) (202) (160) (140) (127) – –
H-4050 kg 123.8 98.9 78.0 68.0 62.1 – –
(lb) (273) (218) (172) (150) (137) – –
H-4075 kg 129.7 104.3 82.6 71.2 65.3 – –
(lb) (286) (230) (182) (156) (144) – –
H-6100 kg 263.1 208.7 165.6 145.2 – – –
(lb) (580) (460) (365) (320) – – –
H-6200 kg 283.5 226.8 179.2 156.5 – – –
(lb) (625) (500) (395) (345) – – –
H-6300 kg 299.4 235.9 188.2 163.3 – – –
(lb) (660) (520) (415) (360) – – –
H-8350 kg 299.4 238.1 188.2 – – – –
(lb) (660) (525) (415) – – – –
H-8500 kg 313.0 249.5 197.3 – – – –
(lb) (690) (550) (435) – – – –
