DC Motors
17
Table H
Service Condition
1
Motors must be specially designed for operation in ambient outside the range of –30 to 40 degrees C
(–22 to 104 degrees F). Special grease is required.
2
"Extreme" service conditions are rare in actual practice. Corresponding lubrication cycles should therefore
be applied with caution. It is also advisable to check with Allen-Bradley for related special instructions.
Table I
Relubrication Periods – Frames C210ATZ - C440ATZ
1
Maximum speed occupying more than 30% of operating time.
2
For Tandem drives increase frequency of lubrication by multiplying values by 0.8.
Frames C210ATZ - C440ATZ
These motors are designed to route new grease directly into the
bearing. The relubrication periods shown in
are offered as a
guide for varying service conditions, speeds, bearing types and
operating hours.
Important: Certain special motors may have a lubrication instruction
plate permanently attached. These specific lubricating
instruction must be followed.
Lubrication Procedure
1. Relubrication with the shaft stationary and a warm motor is
recommended.
2. Locate the grease inlet at the top of the bearing hub, clean the
area and replace the 1/8 inch pipe plug with a grease fitting (if the
motor is not equipped with a grease fitting).
Service
Condition Ambient Temperature
Bearing Load
Atmosphere
Operating
Hours/Day
Standard
–18 to 40 degrees C
(0 to 104 degrees F)
Steady
Clean
8
Severe
–30 to 50 degrees C
(–22 to 122 degrees F)
1
Medium Shock, Vibration
(less than 0.2 in/sec.)
Medium Dirt,
Abrasives,
Corrosion
8 to 24
Extreme
2
–54 to 65 degrees C
(–65 to 149 degrees F)
1
Heavy Shock, Vibration
(more than 0.44 in/sec)
Heavy Dirt,
Abrasives,
Corrosion
8 to 24
Maximum Normal
Operating Speed (RPM)
1
Frame
Relubrication Interval (Months)
2
Standard
Service
Severe
Service
Extreme
Service
3450 and higher
All
9
4
1
2400 - 3449
C210ATZ - C250ATZ
24
9
3
C280ATZ - C400ATZ
9
3
1
1700 - 2399
C210ATZ - C320ATZ
36
12
3
C360ATZ - C400ATZ
18
6
2
UC360ATZ - UC400ATZ
9
3
1
800 - 1699
C210ATZ - C320ATZ
36
24
8
C360ATZ - C400ATZ
36
12
3
UC360ATZ - UC400ATZ
18
6
1
500 - 799
C210ATZ - C320ATZ
48
36
12
C360ATZ - C400ATZ
36
24
8
UC360ATZ - UC400ATZ
18
12
4
499 and lower
C210ATZ - C440ATZ
48
36
12
UC360ATZ - UC440ATZ
24
18
6
