Rockwell Automation 1395 Reel Tension Paster Adapter - Manual (Page 34)

Publication 1395-RTP-5.1 - September 1997
3-14 Start-Up Instructions
IMP/
HOUR
RTP PRESS
SPD. SENSOR
FREQ (HZ)
WEB
VELOCITY
(FT/MIN)
BELT
MOTOR
RPM
PRESS
DRIVE
SHAFT RPM
60000 4266.66 1791.68 1219.41 2000.00
62000 4408.88 1851.40 1260.06 2066.66
64000 4551.11 1911.13 1300.71 2133.33
66000 4693.33 1970.85 1341.35 2200.00
68000 4835.55 2030.57 1382.00 2266.66
70000 4977.77 2090.29 1422.65 2333.33
72000 5119.99 2150.02 1463.29 2400.00
74000 5262.22 2209.74 1503.94 2466.66
75000 5333.33 2239.60 1524.27 2500.00
76000 5404.44 2269.46 1544.59 2533.33
78000 5546.66 2329.18 1585.24 2600.00
80000 5688.88 2388.91 1625.88 2666.66
Table 6: Cross Reference
(Printing Diameter = 15; Gear Teeth = 140)
IMP/
HOUR
RTP PRESS
SPD. SENSOR
FREQ (HZ)
WEB
VELOCITY
(FT/MIN)
BELT
MOTOR
RPM
PRESS
DRIVE
SHAFT RPM
100 7.78 3.27 2.22 3.33
400 31.11 13.09 8.89 13.33
600 46.67 19.63 13.34 20.00
800 62.22 26.18 17.78 26.67
1000 77.78 32.72 22.23 33.33
1200 93.33 39.27 26.67 40.00
2000 155.56 65.45 44.46 66.67
4000 311.11 130.90 88.92 133.33
6000 466.67 196.35 133.37 200.00
8000 622.22 261.80 177.83 266.67
10000 777.78 327.25 222.29 333.33
12000 933.33 392.70 266.75 400.00
14000 1088.89 458.15 311.20 466.67
16000 1244.44 523.60 355.66 533.33
18000 1400.00 589.05 400.12 600.00
Table 5: Cross Reference
(Printing Diameter = 13-11/16; Gear Teeth = 128) (Continued)
