Rockwell Automation Publication 1305-5.2.2 - September 2013 7
1305 Adjustable Frequency AC Drive
Output Config Local Mask 93 Byte — — 01111111
Output 1 Config 90 Text (1) — — Faulted Owners
Output 2 Config 91 Text (1) — — Running Stop Owner 102 Byte — — —
Analog Out Sel 25 Text (1) — — Frequency Direction Owner 103 Byte — — —
Above Freq Val 77 1 Hz 0 400 0 Start Owner 104 Byte — — —
Above Curr Val 142 1% 0% of DRC 150% of DRC 0% of DRC Jog Owner 105 Byte — — —
Faults Reference Owner 106 Byte — — —
Fault Buffer 0 86 Numeric — — — Accel Owner 107 Byte — — —
Fault Buffer 1 87 Numeric — — — Decel Owner 108 Byte — — —
Fault Buffer 2 88 Numeric — — — Fault Owner 109 Byte — — —
Fault Buffer 3 89 Numeric — — — MOP Owner 110 Byte — — —
Clear Fault 51 Text (1) — — Ready Local Owner 137 Byte — — —
Cur Lim Trip En 82 Text (1) — — Default Run Adapter I/O
Line Loss Fault 40 Text (1) — — F03 Enable Data In A1 111 Numeric 0 149 0
Flt Clear Mode 39 Text
(1)
— — Enabled Data In A2 112 Numeric 0 149 0
Diagnostics Data In B1 113 Numeric 0 149 0
Drive Command 58 Byte — — — Data In B2 114 Numeric 0 149 0
Drive Status 59 Text (1) — — — Data In C1 115 Numeric 0 149 0
Drive Alarm 60 Byte — — — Data In C2 116 Numeric 0 149 0
Input Status 55 Byte — — — Data In D1 117 Numeric 0 149 0
Freq Source 62 Text (1) — — — Data In D2 118 Numeric 0 149 0
Freq Command 65 0.01 Hz 0.00 400.00 0.00 Data Out A1 119 Numeric 1 149 1
Drive Direction 69 Text (1) — — Forward Data Out A2 120 Numeric 1 149 1
Motor Mode 43 Text (1) — — — Data Out B1 121 Numeric 1 149 1
Power Mode 44 Text
(1)
— — — Data Out B2 122 Numeric 1 149 1
Drive Type 61 Numeric — — — Data Out C1 123 Numeric 1 149 1
Firmware Ver. 71 Numeric — — — Data Out C2 124 Numeric 1 149 1
Output Pulses 67 1 Cycle 0 65535 — Data Out D1 125 Numeric 1 149 1
Drive Temp 70 1 deg. C 0 100 — Data Out D2 126 Numeric 1 149 1
Set Defaults 64 Text (1) — — Ready Process DIsplay
Masks Process Par 127 Numeric 1 149 1
Logic Mask 92 Byte — — 01111111 Process Scale 128 Numeric -327.68 +327.67 +1.00
Direction Mask 94 Byte — — 01111111 Process Text 1 129 ASCII text — — ?
Start Mask 95 Byte — — 01111111 Process Text 2 130 ASCII text — — ?
Jog Mask 96 Byte — — 01111111 Process Text 3 131 ASCII text — — ?
Reference Mask 97 Byte — — 01111111 Process Text 4 132 ASCII text — — ?
Accel Mask 98 Byte — — 01111111 Process Text 5 133 ASCII text — — ?
Decel Mask 99 Byte — — 01111111 Process Text 6 134 ASCII text — — ?
Fault Mask 100 Byte — — 01111111 Process Text 7 135 ASCII text — — ?
MOP Mask 101 Byte — — 01111111 Process Text 8 136 ASCII text — — ?
(1) See the 1305-5.2 User Manual, Appendix B, Table B.5.
