1397 115VAC Control Interface Card 5
1397-5.18 March, 1997
8.0
7.0
6.5
6.0
5.5
7.5
2.5
2.0
1.5
1.0
.5
0
5 1.5 1.0 2.0 3.0 2.5
0
Mounting Holes (4) – 3.61 mm (0.142) Dia.
214.6 mm
(8.45 In.)
78.7 mm
(3.10 In.)
88.9 mm
(3.5 In.)
224.8 mm
(8.85 In.)
38.1 mm
(1.5 In.)
Mounting Dimensions
