1397 115VAC Control Interface Card 3
1397-5.18 March, 1997
L1
IN1
IN2
IN3
IN4
IN5
L1
IN6
IN7
IN8
CON2
CON3
115V AC Control Interface Card
115V IN
L1
IN9
IN10
L1
Brush Wear
Run
AC Common
Gnd
Earth Ground
115V AC
Stop
Jog
Reverse/Forward
Reference Select
Customer Interlock
Fault Alarm Reset
Coast-to-Stop
REV
ANLG REF 1
INTERLOCK
ANLG REF 2
FWD
Motor Thermostat
1FU
181 2FU
182 3FU
183
Drive
115V AC
L1
L2
1
2
3
4
5
6
7
8
9
10
CON1
DC OUT
+V
Wiring
ATTENTION: Electric Shock can
cause injury or death. Remove all
power before working on this product.
The drive is at line voltage when
connected to incoming AC power.
Before proceeding with any
installation or troubleshooting
activity, disconnect. lockout and tag
all incoming power to the drive. Verify
with a voltmeter than no voltage exists
at terminals L1, L2 and L3 on the drive
input power terminal block.
!
Regulator Board Terminal Strip
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
+24V
Run
Stop
Jog
Reverse/Forward
Reference Select
+24V
Customer Interlock
Fault Alarm Reset
+24V
Brush Wear
Motor Thermostat
+24V
+24V Common
Coast-to-Stop
1
+V
2
3
4
6
7
8
9
10
GND
5
