Technical Specifications Chapter 5
Technical Specifications
Electrical
Nominal Voltage User-selectable, 100V-480Vrms, 1-Phase or 3-Phase Immune to voltage
fluctuation up to ±10% of nominal and transient over voltages typically present
on mains supply (impulse withstand Category II of IEC 60364-4-443)
Frequency 45...65 Hz, auto-sensing
Measurement inputs 1 to 3 channels, Cat. No.: 1068S-3V480K (3-channel)
Up to 6 channels, Cat. No.: 1068S-6V480K (6-channel)
RMS voltage measurement accuracy 0.2% typical, ± 2% maximum (of full-scale)
True rms
Sample rate 5760 sample/second
Waveform capture rate 32 samples/cycle
Time Stamp ±0.1 seconds typical accuracy
Real-time clock synchronized to UTC (NIST standard) daily, via

i-Grid and SNTP protocol
Data Storage Non-volatile event storage > 300 events

Memory cleared after automatic up load to i-Grid.
Voltage Deviation Event detection trigger. 1/2-cycle rms voltage ≤ 87% or ≥115% of set nominal 
Adaptive waveform deviation detection of transient events.
Voltage Deviation Event Storage 8 cycles waveform data (-1...+3 cycles at event start and -3...+1 cycles at the
event end) Continuous rms voltage trend, up to 2 minutes.
Periodic (PRMS) Data Logging Minimum, Maximum and Average rms voltage recorded for each 10-minute
period. Min./Max. are lowest/highest sliding 1/2 -cycle rms period
Power supply and battery backup Powered from Channel 1 (L1-L2 or L1-N), < 25VA load
9VDC external power supply (not provided - for configuration only)
Rechargeable batteries enable measurement & communications during power
interruptions for up to 2 minutes
Mechanical & Environmental
Enclosure NEMA 1 (IP20). Indoor use only.

Only non-conducting pollution (degree II)

Dimensions: 11.4” H x 9.7” W x 3.0” D (291 mm H x 247 mm W x 75 mm D)
Weight 8.5 lb (3.6 kg)
Operating Temperature 0...+ 40 °C (+32...+104 °F)
Storage Temperature -40...+ 75 °C (-40...167 °F)
Relative Humidity 0...95%, non-condensing
Altitude 2000 m (6,562 ft) at +40 °C
Communications
Internet Communications Over port 80 via HTTP protocol. Outgoing only.
Ethernet IEEE 802.3 10 Base-T (10 Mb/s), 8P8C (RJ45) modular connector
Modem (optional) PSTN (analog telephone) RJ11 modular connector, Most global phone systems
supported
Indicators Red and green front-panel LEDs
i-Sense Management Console On-board Web server for configuration and status, password protected.
