Rockwell Automation 1492-CM1771-LD0014F Field Wire Conversion Module - Manual (Page 5)

PN-114286
DIR 10000060097 (Version 01)
Publication 1492-IN050B-EN-E
V. Wiring Diagrams (Cont’d)
There are several key application considerations and system specifications (bottom of drawing) when
using these components (conversion module, cable and input module). Read and understand these
considerations before installation. WARNING
1771-WA Swing Arm
From 1771-IV
1771-WA Swing Arm
From 1771-IV
Conversion Module Installation and Application Considerations
This Bul. 1492 cable consists of 2 separate cables (cable “A” and cable “B”) wired to one 1756-IV16 RTB. Each cable can be either 0.5M
or 1.0M (005=0.5M, 010=1.0M). Ensure that cable A and cable B are connected to the correct module in the conversion.
The input delay times for the 1771-IV module versus the 1756-IV16 module are as follows:
1771-IV 1756-IV16 w/1492-C005005XG
a) Off-to-On Delay 15ms (+/-7ms) 1ms max (plus selectable filter)
b) On-to-Off Delay 15ms (+/-7ms) 2ms max (plus selectable filter)
The 1771-IV module is rated 12 To 24V DC. The 1756-IV16 module is rated 10V To 30V DC only.
Refer to your 1771-IV and 1756-IV16 Installation Manual wiring schematics and diagrams for more details.
[Reference Doc: 41170-989 (Version 00)]
1756-IV16
Conversion Module
1492-CM1771-LD014
Conversion Module
1492-CM1771-LD014
Cable
1492-C005005XG
Conversion: 1771-IV (2) to 1756-IV16 (1)
(5)
B
3
4
5
6
7
A
0
1
2
Black
White
Red
Green
Orange
Blue
White/Black
Red/Black
Green/Black
Orange/Black
Blue/Black
Black/White
Red/White
Green/White
Blue/White
Black/Red
White/Red
Orange/Red
Blue/Red
Red/Green
+DC-0
+DC-0
IN-0
1
IN-1
2
IN-2
3
IN-3
4
IN-4
9
IN-5
10
IN-6
IN-7
5
6
7
8
LOAD
-
+
1
19
3
4
5
6
7
8
9
10
11
12
13
15
16
17
18
20
14
2
24
21
22
23
25
-DC-0
B
3
4
5
6
7
A
0
1
2
Black
White
Red
Green
Orange
Blue
White/Black
Red/Black
Green/Black
Orange/Black
Blue/Black
Black/White
Red/White
Green/White
Blue/White
Black/Red
White/Red
Orange/Red
Blue/Red
Red/Green
+DC-1
IN-8
11
IN-9
12
IN-10
13
IN-11
14
IN-12
19
IN-13
20
IN-14
IN-15
15
16
17
18
LOAD
-
+
1
19
3
4
5
6
7
8
9
10
11
12
13
15
16
17
18
20
14
2
24
21
22
23
25
-DC-1
+DC-0
+DC-1
INPUT 03
INPUT 02
INPUT 01
INPUT 00
INPUT 07
INPUT 06
INPUT 05
INPUT 04
+DC-1
INPUT 11
INPUT 10
INPUT 09
INPUT 08
INPUT 15
INPUT 14
INPUT 13
INPUT 12
Cable A
Cable B
