Rockwell Automation 1494V-DSxx Series D Variable Depth Disconnect Switch - Manual (Page 8)

(8)
Trailer Fuse Block Installation (Switch Rating 30A - 100A)
Note: Not required for non-fusible disconnect switch applications.
1
2
23 - 37 lb-in
Trailer Fuse Block Location
Install Trailer Fuse Block
30 Amp Trailer Fuse Block (1494V-FS30)
Torque (lb-in) Fuse
23-37
2-27/32"
5-5/8"
2-27/32"
4-3/16"
3-5/8"
6-1/8"
3"
4-3/16"
30
30
30
30
60
60
60
60 250
600
600
600
250
600
600
600 H/R
H/R
J
HRCII-C
H/R
H/R
J
HRCII-C
22-37 90-110 150-165
23-37 22-37 20-25 20-25
23-37 16-22 90-110 150-165
Amps Voltage Class Fuse
Block
A
Fuse
Clip
Lug to
Terminal
Wire
into Lug
60 Amp Trailer Fuse Block (1494V-FS60)
Torque (lb-in) Fuse
23-37
2-27/32"
5-5/8"
2-27/32"
4-3/16"
3-5/8"
6-1/8"
3"
4-3/16"
4-15/16"
8-1/8"
30
30
30
30
60
60
60
60
100
100
250
600
600
600
250
600
600
600
600
600 H/R
H/R
J
HRCII-C
H/R
H/R
J
HRCII-C
J
H/R
23-37 40-60 45-50
23-37 16-22 40-60 45-50
Amps Voltage Class Fuse
Block
A
Fuse
Clip
Lug to
Terminal
Wire
into Lug
100 Amp Trailer Fuse Block (1494V-FS100)
Torque (lb-in) Fuse
4-3/16"
3-9/16"
6-11/16"
4-11/16"
6-11/16"
8-11/16"
5-1/2"
7-9/16"
6-1/4"
60
60
60
60
100
100
100
100
200
250
600
600
600
250
600
600
600
600 H/R
J
H/R
HRCII-C
H/R
H/R
J
HRCII-C
J
Amps Voltage Class Fuse
Block
A
Fuse
Clip
Lug to
Terminal
Wire
into Lug
A
2-1/4"
PN-47400
DIR 10000056505 (Version 00)
(2) 11/64" Dia. Holes
