Rockwell Automation 1494V-DSxx Series D Variable Depth Disconnect Switch - Manual (Page 5)

PN-47400
DIR 10000056505 (Version 00)
Enclosure without Handle Cutout
1
To make slot drill (3) 1/2" diameter holes and remove burrs
Top Handle Hole
Top Handle Hole
Locate Handle
Right Hand Flange
Enclosure Dimensions
Left Hand Flange
(2) .265 Dia. Holes
Drill Handle Holes
B
C
A
C
B
A
2
F
G
H
J
H
(5)
L Enclosures with a Flange Thickness less than 3/16" use dimensions below to install disconnect handle.
L Enclosures with a Flange Thickness 3/16" and greater use dimensions in alternate Mounting Kit 1494V-H3 to install disconnect
handle.
L Multi-Door Enclosures may require the need for a more rigid flange / mounting plate system, such as a Channel Support Kit. Use
dimensions in Channel Support Kit 1494V-H15, if handle is mounted on top of the channel.
F
4 - 11/16"
4 - 11/16"
4 - 11/16"
G
1 - 9/16"
1 - 9/16"
1 - 9/16"
H
1"
1"
1"
J
7/8"
7/8"
7/8" 1 - 1/16"
C
(max)
1 - 1/16"
1 - 1/16"
B
(min)
1 - 1/8"
1 - 1/8"
1 - 1/8"
A
(min)
4 - 5/8"
6 - 1/16"
10 - 1/8"
NEMA
SIZE
30A, 60A
200A
100A
