B-4 Parameter Information
Table B.1 (cont.) Parameter List
① Read-only capability.
② The scale factor is 100 when Motor FLC, parameter 70, has a programmed value of up to 10.0 Amps; above 10.0 Amps, the scale factor is 10.
Group
Parameter
Description
Parameter
Number
Display
Units
Scale
Factor
Minimum Maximum
Default
Setting User
Setting
Calibrate
Overload
Class
36 — — Off, 10, 15, 20, and 30 Off
Overload
Reset
88 — — Manual-Auto Manual
Motor HP
Rating
79 HP 10 0.0 6,553.5 0.0
Motor kW
Rating
80 kW 10 0.0 6,553.5 0.0
Line Voltage 69 Volts 1 0 9999 480
Motor FLC 70 Amps 10 1.0 999.9 1.0
Service
Factor
84 — 100 0.01 1.99 1.15
Motor Code
Letter
72 — —
A, B, C, D, E, F, G, H, J, K, L,
M, N, P, R, S, T, U, and V
G
LRC Ratio 81 — 10 0.0 19.9 0.0
Converter
Rating
74 — — None, 20, 180, 630 None
CT Ratio 75 — —
5, 50, 75, 100, 150, 200,
250, 300, 400, 500, 600, 750,
800, 1000, 1200 :5
5:5
Calibration 76 — — Off, Activate Off
Enter Calib.
Amps
77 Amps ② 0.01 999.9 0.0
Current
Phase A ①
4 Amps 10 — — —
Parameter
Mgmt.
17 — —
Ready, Default Init.
Recll Frm EE,Store In EE
Ready
