Rockwell Automation 20G PowerFlex 750-Series Power Jumpers User Manual
Page 6
6
Rockwell Automation Publication 750-IN011E-EN-P - February 2014
PowerFlex 750-Series Power Jumpers
5
C
D
E
PE-A Installed
PE-B Not Installed
PE-A Installed
PE-B Installed
Solid Ground
Install jumper screws at “PE-A” (MOV/Input Filter
Cap) and “PE-B” (CM Cap).
See
for recommended torque.
Non-Solid Ground
Remove both jumper screws.
6
C
D
E
F
PE-A jumper wire
connected to ground.
PE-B jumper wire
insulated/
disconnected from
ground.
PE-A jumper wire
and PE-B jumper
wire connected to
ground.
Solid Ground
Connect the MOV/Input Filter Cap jumper wire (PE-
A) and the CM Cap jumper wire (PE-B) to ground.
See
for recommended torque.
Non-Solid Ground
Insulat the MOV/Input Filter Cap jumper wire (PE-
A) and the CM Cap jumper wire (PE-B) from
ground.
7
C
D
E
F
PE-A jumper wire
connected to ground.
PE-B jumper wire
insulated/
disconnected from
ground.
PE-A jumper wire
and PE-B jumper
wire connected to
ground.
Solid Ground
Connect the MOV/Input Filter Cap jumper wire (PE-
A) and the CM Cap jumper wire (PE-B) to ground.
See
for recommended torque.
Non-Solid Ground
Insulate the MOV/Input Filter Cap jumper wire (PE-
A) and the CM Cap jumper wire (PE-B) from
ground.
Frame
Vo
lt
ag
e
Co
de
Factory Default Jumper Settings
Power Source Type
Catalog Code “A”
Catalog Code “J”
PE-B
PE-A
DC+
PE-B
PE-A
E4
Insulated
Connected
Insulated
Connected
PE-B
PE-A
Insulated
Connected
Insulated
Connected
